3.5mm 8MP
Fixed Focal M-12 Lens
1/1.7” Image Format
| Focal Length | 3.5 mm |
| Image Format (max) | 1/1.7" |
| Image Circle (max) | 9.2 mm |
| Resolution | 8 MP |
| Iris | Fixed Aperture (f/2.2) |
| Spectral Transmissibility | 660 nm IR Cut Filter |
| Lens Type | Wide Angle |
| Distortion | -7% F-Θ @8.0 mm |
| Back Focal Length | 4.4 ± 0.3 |
| Mount | M-12 |
| Construction | Hybrid (Glass/Plastic) |
| Environmental Protection | IP67 + HY |
| Max Diameter | 14.0 mm |
| Weight | 4.3 g |
3.65mm 12MP
Fixed Focal M-12 Lens
1/3” Image Format
|
Sensor |
CCD/CMOS |
|
Image Format |
1/3" |
|
Focal Length |
3.65mm |
|
Aperture, (F-Stop) |
F2.8 |
|
Back Focal Length |
N/A |
|
Field of View (D x H x V) |
94° x 82° x 69° |
|
Operation |
Iris Fixed Focus Manual |
|
Distortion |
<0.5% |
|
Minimum Object Distance |
0.2m |
|
Mount |
M-12 Board |
|
Dimensions (Ø x L) |
20mm x 20.74mm |
|
Weight |
8g |
3.6mm 5MP
Fixed Focal M-12 Lens
1/2.5” Image Format
|
Image Format |
1/2.5" |
|
Focal Length |
3.6mm |
|
Aperture, (F-Stop) |
F1.8 |
|
Back Focal Length |
7.3mm |
|
Field of View (D x H x V) |
128° x 96.4° x 69.8° |
|
Effective Diameter |
N/A |
|
Operation |
Iris Fixed Focus Manual |
|
Distortion |
<-29% |
|
Minimum Object Distance |
0.2m |
|
Lens Construction |
6 glasses |
|
Mount |
M-12 Board |
|
Dimensions (Ø x L) |
14mm x 18.08mm |
|
Weight |
5.0g |
3.6mm Megapixel
Fixed Focal M-12 Lens
1/3” Image Format
|
Image Format |
1/3" |
|
Focal Length |
3.6mm |
|
Aperture, (F-Stop) |
F1.8 |
|
Back Focal Length |
6.59mm |
|
Field of View (D x H x V) |
100.2° x 77° x 54° |
|
Operation |
Iris Fixed Focus Manual |
|
Distortion |
34.1% |
|
Minimum Object Distance |
0.2m |
|
Lens Construction |
6-5 |
|
Mount |
M-12 Board |
|
Dimensions (Ø x L) |
14mm x 16.6mm |
|
Weight |
4.8g |
3.8mm 16MP
Fixed Focal M-12 Lens
1/2.3” Image Format
|
Sensor |
CCD/CMOS |
|
Image Format |
1/2.3" |
|
Focal Length |
3.8mm |
|
Aperture, (F-Stop) |
F2.8 |
|
Back Focal Length |
5.59mm |
|
Field of View (D x H x V) |
95° x 82° x 65° |
|
Effective Diameter |
N/A |
|
Operation |
Iris Fixed Focus Manual |
|
Distortion |
-2.8% |
|
Minimum Object Distance |
0.2m |
|
Lens Construction |
5-4 |
|
Mount |
M-12 Board |
|
Dimensions (Ø x L) |
20mm x 25.3mm |
|
Weight |
15g |
4.0mm 5MP Fixed Focal M-12 Lens
Fixed Focal M-12 Lens
1/2.5” Image Format
|
Sensor |
CCD/CMOS |
|
Image Format |
1/2.5" |
|
Focal Length |
4.0mm |
|
Aperture, (F-Stop) |
F2.0 |
|
Back Focal Length |
5.7mm |
|
Field of View (D x H x V) |
112° x 90° x 67° |
|
Effective Diameter |
N/A |
|
Operation |
Iris Fixed Focus Manual |
|
Distortion |
<-42.8% |
|
Minimum Object Distance |
0.2m |
|
Lens Construction |
N/A |
|
Mount |
M-12 Board |
|
Dimensions (Ø x L) |
14mm x 17.6mm |
|
Weight |
5.0g |
4.0mm M-12 Lens
Fixed Focal M-12 Lens
1/3” Image Format
|
Sensor |
CCD/CMOS |
|
Image Format |
1/3" |
|
Focal Length |
4.0mm |
|
Aperture, (F-Stop) |
F2.0 |
|
Back Focal Length |
5.8mm |
|
Field of View (D x H x V) |
97° x 70.1° x 52.0° |
|
Effective Diameter |
N/A |
|
Operation |
Iris Fixed Focus Manual |
|
Minimum Object Distance |
40cm |
|
Lens Construction |
5-4 |
|
Mount |
M-12 |
|
Dimensions (Ø x L) |
Ø 15mm x 15.7mm |
|
Weight |
6.1g |
4.2mm Megapixel
Fixed Focal M-12 Lens
1/3” Image Format
|
Sensor |
CCD/CMOS |
|
Image Format |
1/3" |
|
Focal Length |
4.2mm |
|
Aperture, (F-Stop) |
F1.8 |
|
Back Focal Length |
7.21mm |
|
Field of View (D x H x V) |
89° x 71° x 49.5° |
|
Operation |
Iris Fixed Focus Manual |
|
Distortion |
N/A |
|
Minimum Object Distance |
0.2m |
|
Lens Construction |
6-5 |
|
Mount |
M-12 x 0.5-6g Board |
|
Dimensions (Ø x L) |
14mm x 16mm |
|
Weight |
5.1g |
4.3mm 14MP
Fixed Focal M-12 Lens
1/2.3” Image Format
|
Sensor |
CCD/CMOS |
|
Image Format |
1/2.3" |
|
Focal Length |
4.3mm |
|
Aperture, (F-Stop) |
F3.0 |
|
Back Focal Length |
3.62mm |
|
Field of View (D x H x V) |
82° x 72° x 56° |
|
Operation |
Iris Fixed Focus Manual |
|
Distortion |
-1.2% |
|
Minimum Object Distance |
0.2m |
|
Mount |
M-12 Board |
|
Dimensions (Ø x L) |
14mm x 19.18mm |
|
Weight |
8g |
4.3mm 14MP
Fixed Focal M-12 Lens - IR Filter
1/2.3” Image Format
|
Sensor |
CCD/CMOS |
|
Image Format |
1/2.3" |
|
Focal Length |
4.3mm |
|
Aperture, (F-Stop) |
F3.0 |
|
Back Focal Length |
3.62mm |
|
Field of View (D x H x V) |
82° x 72° x 56° |
|
Operation |
Iris Fixed Focus Manual |
|
Distortion |
-1.2% |
|
Minimum Object Distance |
0.2m |
|
Mount |
M-12 Board |
|
Dimensions (Ø x L) |
14mm x 19.18mm |
|
Weight |
8g |
4.3mm M-12 Lens
Fixed Focal M-12 Lens
1/3” Image Format
|
Sensor |
CCD/CMOS |
|
Image Format |
1/3" |
|
Focal Length |
4.3mm |
|
Aperture, (F-Stop) |
F2.0 |
|
Back Focal Length |
6.3mm |
|
Field of View (D x H x V) |
78.0° x 62.1° x 46.3° |
|
Operation |
Iris Fixed Focus Manual |
|
Distortion |
-18.6 |
|
Minimum Object Distance |
40cm |
|
Lens Construction |
|
|
Mount |
M-12 |
|
Dimensions (Ø x L) |
Ø 14.8mm x 16.1mm |
|
Weight |
5.7g |
4.4mm
Fixed Focal M-12 Lens
1/3” Image Format
|
Sensor |
CCD/CMOS |
|
Image Format |
1/3" |
|
Focal Length |
4.4mm |
|
Aperture, (F-Stop) |
F1.9 |
|
Back Focal Length |
6.40 - 6.36mm |
|
Field of View (D x H x V) |
84.9° x 65.4° x 47.9° |
|
Iris |
Fixed |
|
Focus |
Manual |
|
Distortion |
-26.14% |
|
Minimum Object Distance |
0.40m |
|
Mount |
M-12 Board |
|
Dimensions (Ø x L) |
14.0mm x 24.0mm |
|
Weight |
7.0g |
4.6mm
Fixed Focal M-12 Lens
1/3” Image Format
|
Image Format |
1/3" |
|
Focal Length |
4.6mm |
|
Aperture (F-Stop) |
F2.0 |
|
Back Focal Length |
5.63mm |
|
Field of View (D x H x V) |
80.0° x 62.0° x 46.0° |
|
Iris |
Fixed |
|
Focus |
Manual |
|
Distortion |
-22% |
|
Minimum Object Distance |
0.20m |
|
Mount |
M-12 Board |
|
Dimensions (Ø x L) |
14.0mm x 18.0mm |
|
Weight |
4.7g |
3' Cable USB connector to a Female 4 Pin JST connector Used with: RHP-BOS-RC-IF, RHP-BOS-RC-HD-IF, RHP-BOS-LVDS, RHP-BOS-CL-SY-IF, RHP-BOS-DS-IF
5.4mm 10MP
Fixed Focal M-12 Lens
1/2.3” Image Format
|
Sensor |
CCD/CMOS |
|
Image Format |
1/2.3" |
|
Focal Length |
5.4mm |
|
Aperture (F-Stop) |
F2.5 |
|
Back Focal Length |
6.6mm |
|
Field of View (D x H x V) |
70° x 60° x 46° |
|
Iris |
Fixed |
|
Focus |
Manual |
|
Distortion |
-2% |
|
Minimum Object Distance |
0.2m |
|
Mount |
M-12 Board |
|
Dimensions (Ø x L) |
14.0mm x 18.74mm |
|
Weight |
8g |
