Imaging Source DMK 37AUX178 USB 3.1 Monochrome Industrial Camera

$493.00

• 1/1.8 inch Sony CMOS STARVIS sensor (IMX178)
• 3,072x2,048 (6.3 MP), up to 60 fps
• Rolling shutter

SKU: DMK 37AUX178

$493.00

Description

Specifications

Downloads

Imaging Source DMK 37AUX178

USB 3.1 monochrome industrial camera

The Imaging Source DMK 37AUX178 USB 3.1 monochrome industrial cameras are equipped with highly-sensitive, low-noise Sony Pregius Global shutter sensors which deliver outstanding image quality and good NIR sensitivity. The DMK 37AUX178 camera can automatically control gain and exposure time. These automatic functions are enabled by default.

The USB3 Vision standard (USB 3.1- Gen. 1), ensures stability and compatibility for easy integration and flexible configuration. Even at high frame rates, the DMK 37AUX178 delivers distortion-free images and are well-suited for applications such as intelligent traffic systems (ITS), automated optical inspection (AOI) and microscopy.

Dynamic Range

12 bit

Video Format

3072 × 2048 (6.3 MP)

Sensor Type

CMOS STARVIS

Sensor Specification

Sony IMX178

Shutter

Rolling

Format

1/1.8 inch

Pixel Size

H: 2.4 µm x V: 2.4 µm

6.3 MP

Resolution

3072 x 2048

FPS

60 FPS

Mono/Color

Monochrome

Lens Mount

C/CS

Interface

PoE, USB 3.1

Supply Voltage

4.75 VDC to 5.25 VDC

Current Consumption

Approx. 320 mA @ 5 VDC

Auto Iris Control

Trigger

I/O

Dimensions (H x W x L)

H: 36 mm x W: 36 mm x L: 25 mm

Mass

70g

Adjustable Shutter

20 µs to 60 s

Gain

0 dB to 48 dB

White Balance

N/A

Temperature (Operating)

-5 °C to 50 °C

Temperature (Storage)

-20 °C to 80 °C

Humidity (Operating)

20 % to 80 % (non-condensing)

Humidity (Storage)

20 % to 95 % (non-condensing)
