Imaging Source DMK 33UX183 USB 3.0 Monochrome Microscope Camera

$776.00

•1 inch Sony CMOS Exmor sensor (IMX183CLK)
•5,472x3,648 (20 MP), up to 18 fps
•Rolling shutter
•Trigger and I/O inputs
•Windows and Linux software included

SKU: DMK 33UX183

$776.00

Description

Specifications

Downloads

Imaging Source DMK 33UX183

USB 3.0 monochrome industrial camera

The Imaging Source 20 megapixel industrial camera (DFK 33UX183) has been designed to be a cost-effective, versatile solution for demanding applications.

Thanks to the camera's USB 3.0 interface, 5,472×3,648, up to 18 fps is available on the host PC. The camera ships with Sony's 1 inch Sony CMOS Exmor sensor (IMX183CQJ) technology, and allows a maximum resolution of 20 megapixels.

Key Features:

1 inch Sony CMOS Exmor sensor (IMX183CLK)
5,472×3,648 (20 MP), up to 18 fps
Rolling shutter
Trigger and I/O inputs
Windows and Linux software included

Dynamic Range

12 bit

Video Format

5472 × 3648 (20 MP)

IR-Cut Filter

Sensor Type

CMOS Exmor

Sensor Specification

Sony IMX183

Shutter

Rolling

Format

1 inch

Pixel Size

H: 2.4 µm x V: 2.4 µm

20 MP

Resolution

5472 x 3648

FPS

18 FPS

Mono/Color

Monochrome

Iris

Lens Mount

C/CS

Interface

PoE, USB 3.0

Supply Voltage

4.75 VDC to 5.25 VDC

Current Consumption

Approx. 660 mA @ 5 VDC

Auto Iris Control

Trigger

Yes

I/O

Yes

Dimensions (H x W x L)

H: 29 mm x W: 29 mm x L: 43 mm

Mass

65g

Adjustable Shutter

50 µs to 30 s

Gain

0 dB to 27.04 dB

Temperature (Operating)

-5 °C to 50 °C

Temperature (Storage)

-20 °C to 80 °C

Humidity (Operating)

20 % to 80 % (non-condensing)

Humidity (Storage)

20 % to 95 % (non-condensing)
