Imaging Source DFM 36CX290-ML FPD-Link III color board camera

$344.00

1/2.8 inch Sony CMOS STARVIS sensor (IMX290)
1,920x1,080 (2.1 MP), up to 60 fps
Rolling shutter
Linux software included

SKU: DFM 36CX290-ML

$344.00

Description

Specifications

Downloads

DFM 36CX290-ML

FPD-Link III color board camera

The Imaging Source DFM 37CX290-ML MIPI CSI-2 camera with FPD-Link III serializer boards offer nearly the same feature set as MIPI CSI-2 cameras, but allow cable lengths up to 15m. Image data, commands and power supply are transmitted via a thin coaxial cable. The FPD-Link board cameras can be used with NVIDIA Jetson Nano, NVIDIA Jetson AGX Xavier as well as Raspberry Pi 4 and feature the latest Sony and ONSemi CMOS sensors (rolling or global shutter).

The board cameras are suitable for single or multi-camera embedded systems for automotive, IoT and standard machine vision applications.

Dynamic Range

12 bit

Video Format

1920 x 1080 (2.1 MP)

IR-Cut Filter

Sensor Type

CMOS STARVIS

Sensor Specification

Sony IMX290

Shutter

Rolling

Format

1/2.8 inch

Pixel Size

H: 2.9 µm x V: 2.9 µm

2.1 MP

Resolution

1920 x 1080

FPS

60 FPS

Mono/Color

Color

Lens Mount

M12x0.5, optional

Interface

FPD-Link III

Supply Voltage

27 VDC to 10 VDC

Current Consumption

Approx. 110 mA @ 18 VDC

Auto Iris Control

Trigger

I/O

Yes

Dimensions (H x W x L)

H: 30 mm x W: 30 mm x L: 27.5 mm

Mass

12g

Adjustable Shutter

15 µs to 1 s

Gain

0 dB to 72 dB

Temperature (Operating)

-5 °C to 45 °C

Temperature (Storage)

-20 °C to 60 °C

Humidity (Operating)

20 % to 80 % (non-condensing)

Humidity (Storage)

20 % to 95 % (non-condensing)
