Imaging Source DFK 33UX287 USB 3.0 Color Industrial Camera

$401.00

•1/2.9 inch Sony CMOS Pregius sensor (IMX287LLR)
•720x540 (0.4 MP), up to 539 fps
•Global shutter
•Trigger and I/O inputs
•Windows and Linux software included

SKU: DFK 33UX287

$401.00

Description

Specifications

Downloads

Imaging Source DFK 33UX287

USB 3.0 color industrial camera

The Imaging Source DFK 33UX287 color industrial camera has a USB 3.0 interface and is the perfect solution for many industrial automation, quality assurance, security, surveillance and medical applications. The color camera ships with the very sensitive 1/2.8 inch Sony CMOS Pregius IMX287LQR sensor. With up to 143 images per second, the DFK 33UX287 is a low cost, yet highly versatile imaging solution. The camera includes a C to CS mount adapter, making it compatible to C and CS mount lenses. Using the optional CS to M12 board lens adapter, the camera is also compatible to M12 board lenses.

The Imaging Source authors and supports drivers, SDKs, extensions and end-user software for Microsoft Windows, which can be freely downloaded from our web site. Extensions for Microsoft Windows enable the DFK 33UX287 to be integrated in to common machine vision software libraries, such as LabView and OpenCV. Furthermore, we author and support open source Linux drivers and software (Apache License 2.0) to integrate the camera into popular distributions. Download the Linux source code at GitHub.

Resolution

720 x 540

Dynamic Range

12 bit

Video Format

720 × 540 (0.4 MP)

IR-Cut Filter

Yes

Sensor Type

CMOS Pregius

Sensor Specification

Sony IMX287

Shutter

Global

Format

1/2.9 inch

Pixel Size

H: 6.9 µm x V: 6.9 µm

0.4 MP

FPS

539 FPS

Mono/Color

Color

Iris

Lens Mount

C/CS

Interface

PoE, USB 3.0

Supply Voltage

4.75 VDC to 5.25 VDC

Current Consumption

Approx. 660 mA @ 5 VDC

Auto Iris Control

Trigger

Yes

I/O

Yes

Dimensions (H x W x L)

H: 29 mm x W: 29 mm x L: 43 mm

Mass

65g

Adjustable Shutter

1 µs to 30 s

Gain

0 dB to 48 dB

White Balance

-2dB to 6dB

Temperature (Operating)

-5 °C to 50 °C

Temperature (Storage)

-20 °C to 80 °C

Humidity (Operating)

20 % to 80 % (non-condensing)

Humidity (Storage)

20 % to 95 % (non-condensing)
