New Thermal Camera Models and the Boson GUI 3.0 Provide More Flexibility and Development Support Features for Industrial, Commercial, and Defense Integrators
January 18, 2022 – The Teledyne FLIR radiometric Boson® thermal infrared camera module is now available in five additional configurations. The new models offer an 8°, 18°, 32°, 50°, or 95° horizontal field of view (FOV), are 640 x 512 resolution, and further enable development of next-generation thermal imaging products and systems. To streamline design and testing while minimizing development cost, developers can also leverage the new Boson GUI 3.0 and its key radiometric command capabilities with the Boson thermal camera module.
“The five new Boson models feature radiometric temperature measurement, meaning the cameras capture the temperature data of every pixel in every frame of a scene,” said Dan Walker, vice president, product management OEM, Teledyne FLIR. “Used in unmanned aerial systems, firefighting, automotive, security, surveillance, and industrial inspection products, these new models offer greater flexibility and options in supporting industrial, commercial, and defense integrators requiring high thermal image resolution within a small, lightweight, and low-power package.”
The Boson GUI 3.0 provides the ability to quickly access and adjust radiometry settings, critical to high-speed integration cycles balancing schedule, cost, and performance. Optimizing radiometric parameters and using spot meters and regions of interest (ROI) with real-time statistics allow for optimization during development testing and tuning. Extensive isotherm controls, commonly used in products for industrial inspection and emergency response UAS missions, enable the GUI to highlight objects in the scene at temperatures of interest. Data fusion, an important capability for systems using complementary sensors such as visible cameras, can be explored using the Boson GUI 3.0 external sync capability.
All Boson thermal camera modules feature FLIR infrared video processing architecture, noise reduction filters, and local-area contrast, utilizing a high sensitivity 12-micron pixel pitch detector that provides high-resolution thermal imaging in a small, lightweight, and low-power package. The image processing capabilities accommodate industry-standard communication interfaces, including visible CMOS and USB.
The new Teledyne FLIR Boson Radiometric camera core models are available globally through Teledyne FLIR and preferred distributors. The Boson GUI 3.0 is available for Windows 10 64-bit systems, while the predecessor Boson GUI 1.4.4, operating on 32-bit systems, remains available. For more information about Boson radiometric thermal camera modules, please visit https://oemcameras.com
RELATED ARTICLES
FLIR Duo and Duo R Dual Sensor Drone Cameras
by Eirik Solberg
on Feb 01 2017
Last Month at the 2017 Consumer Electronics Show (CES) in Las Vegas, Nevada, FLIR announced their latest camera for personal and commercial drone use, the FLIR Duo.
As the most affordable dual thermal and visible sensor drone camera equipped with FLIR’s smallest and lightest Lepton thermal camera core, operators are no longer constrained by daylight. The FLIR Duo provides a sixth sense, the power to see objects over 100 yards away in complete darkness, smoke and light fog. Equipped with a 160×120 thermal camera and High-Definition (HD) 1080 color camera, FLIR Duo allows operators to swap between the two cameras mid-flight or view both in a picture-in-picture mode via the FLIR UAS app, so no flight time is lost swapping out cameras. FLIR’s proprietary MSX image processing algorithm embosses the thermal image with key details from the visible camera, resulting in the sharpest dual-spectrum image in the market.
FLIR also announced a second FLIR Duo camera, the FLIR Duo R priced at $1,299.99. A more professional version of the FLIR Duo, the FLIR Duo R adds accurate temperature measurement capabilities for commercial applications including agricultural, construction, civil engineering, building inspection, and public safety use cases.
Visit www.oemcameras.com to learn how you can take thermal to new heights.
First Responders: FLIR AERIAL Drone Packages available from OEMCameras.com
by Eirik Solberg
on May 02 2016
The new FLIR Aerial First Responder Kit will bundle the DJI Inspire 1 drone with the DJI Zenmuse XT stabilized thermal camera powered by FLIR and offered in two configurations, Basic and Advanced.
The Basic bundle includes the 336×256 resolution Zenmuse XT with a 45-degree lens, while the Advanced package sports a higher, 640×480 resolution Zenmuse XT and a 45-degree lens. The Advanced package also includes a second controller so that one controller can be dedicated to aircraft control and the other used for camera control and configuration. All controllers receive live digital video downlink on the Apple iPad Mini included with each controller.
The FLIR-equipped DJI drone packages offer first responders added support with the ability to see through smoke, assess the scene from an aerial perspective, and keep track of their personnel in large fire scenes. For search and rescue operators, they offer valuable observation capabilities in dangerous environments when time is critical.
By combining the flight stability, gimbal technology, mobile app integration, and image transmission of the popular and proven DJI Inspire 1 with the industry-leading thermal imaging technology of FLIR in the Zenmuse XT, these packages are the ultimate solutions for reliable, rapidly-deployable aerial thermal imaging.
The FLIR Aerial First Responder Kits start at $10,450 USD. To learn more about package options, visit www.OEMCameras.com
FLIR VUE PRO R - Radiometric drone camera for accurate airborne temperature measurements
by Eirik Solberg
on May 02 2016
The new Vue Pro R from FLIR gives both drone operators and certified thermographers the power to gather accurate, non-contact temperature measurements from an aerial perspective. Every still image the Vue Pro R saves contains accurate, calibrated temperature data embedded in every pixel, adding even more value to your sUAS operations and services than ever.
Keeping the same industry-leading thermal imaging quality, interfaces, and capability as the best-selling Vue Pro, the Vue Pro R adds fully radiometric data-gathering to sUAS applications as diverse as building and roof inspections, power grid inspections, infrastructure analysis, precision agriculture, and public safety.
Radiometry
The Vue Pro R is more than a thermal imager – it captures accurate, non-contact temperature measurements from an aerial perspective and saves images with calibrated temperature data embedded in every pixel.
Get FLIR Tools
On-Board Recording
Vue Pro R captures regular JPEGs and fully radiometric R-JPEGs that can be fully analyzed in FLIR Tools thermography analysis and reporting software. It also records 8-bit digital video in MJPEG or H.264 formats, and 14-bit TIFFs right on the camera so you won’t lose any of your data to transmission loss. Imagery is saved to the micro-SD card and can be retrieved either directly from the card or by plugging the camera into a USB cable, where your computer will see it as a storage device.
MAVLink Integration & Camera Control
Like Vue Pro, Vue Pro R’s Accessory Port connection gives you access to MAVLink commands camera controls over PWM commands, so you can select color palettes, start and stop recording, or trigger the camera’s e-zoom in-flight from your radio controller. If MAVLink is enabled, two camera controls are available; without MAVLink you can control up to four camera controls.
Easy to Configure
Vue Pro R comes with a built-in, low-power Bluetooth module, so you can easily configure your camera with our custom iOS or Android apps before you take off. Change color palettes, set your image optimization features, configure your PWM inputs, and start recording all without lugging a computer to the field.
With the same powerful thermal imaging core used in the most popular cameras in the world, FLIR Vue Pro R brings affordable, calibrated radiometry to drone operators, making it perfect for myriad applications like:
Roof inspections
Power line inspections
Substation inspections
Cell tower inspections
Search and rescue
Precision agriculture
Security
Surveying
Exclusive: FLIR VUE PRO 35mm Lens
by Eirik Solberg
on Mar 04 2016
Now available and in stock. FLIR VUE PRO 35mm Lens:
640 Version: 18°(H) x 14°(V) FoV
336 Version: 9.3°(H) x 7.1°(V) FoV
More Info: OEMCameras.com
Designed for professional use the FLIR VUE PRO is more than a thermal camera with Video and Image Capture capabilities adding tremendous value to your sUAS operations and services.
FLIR VUE Pro 640x480 Comparison: 9mm, 13mm, 19mm
by Eirik Solberg
on Dec 15 2015
Last week we compared the FLIR VUE Pro cameras side-by-side.
This video shows the difference in Field of View for the VUE Pro 640×480 9mm, 13mm and 19mm.
The 19mm image is 32°(H) x 26°(W) FoV.
The 13mm image is 45°(H) x 37°(W) FoV.
The 9mm image is 69°(H) x 56°(W) FoV.
The FLIR VUE Pro comparison matrix
by Eirik Solberg
on Nov 16 2015
Thermal Camera mounted on a Formula 1 Race Car.
The speed reaches over 290 km/h (180 mph).
by Eirik Solberg
on Nov 11 2015
The FLIR VUE PRO will be shipping out in just another week or so and OEMCameras.com was one of the first to receive the FLIR VUE PRO for review.
Here’s a look at some of the great features of the VUE PRO.
Designed for professional use, FLIR Vue Pro is more than a thermal camera, it is a thermal measurement instrument and data recorder that adds tremendous value to your sUAS operations and services.
FLIR Vue Pro gives you in-flight control of two camera functions through direct PWM connections, and it’s MAVLink compatibility makes it ready for the easy image stitching required for mapping, survey, and precision agriculture applications. Plus, it’s compatible with Pix4Dmapper right out of the box.
The convenient mobile app makes pre-flight camera set-up and configuration quick and easy so you won’t have to drag a computer out to your flying site just in case you need to change a camera setting.
Outbreak Prevention by Detecting Elevated Body Temperatures with Thermal Imaging Systems
by Eirik Solberg
on Oct 15 2014
With the ongoing 2014 West African Ebola Outbreak escalating to 10,000 reported cases with 4,500 deaths in Nigeria, Liberia, and Sierra Leone; the World Health Organization has stated “the current epidemic of EVD, caused by Ebola virus, is the most severe outbreak of Ebola since the finding of ebolaviruses in 1976. The epidemic has caused significant mortality, with a Case Fatality Rate (CFR) reported as 71%.”
With no signs of slowing down or an accessible cure, governments are now taking necessary steps to prevent the virus from spreading into foreign borders. One tool being thermal imaging cameras for scanning high body temperatures among large crowds of people. The procedure is a fast, easy, and non-invasive method to identity and test potential carriers of the disease who show signs of fever-like symptoms.
Learn About Our Thermal Fever Detection System
Benefits of thermal imaging as a screening tool:
Quick and non-invasive application
Real-time images that take less than a second, allowing crowds to keep moving
Rapid screening of large numbers of people
Heat pictures detect and display even the smallest temperature differences
Options allow you to create a visual heat map of skin temperatures in real time
FLIR Quark 336 and 640 Thermal Imaging Camera Cores
by Eirik Solberg
on Jun 03 2013
The FLIR Quark Thermal Infrared Camera Core:The smallest, lightest thermal camera of it’s kind.
The FLIR Quark 336 delivers FLIR’s reputable performance in a compact lightweight package. The uncompromising size of the FLIR Quark 336 offers a new variety of uses for R&D applications where size and weight are important factors. Weighing less than 25g and 22 x 22mm in size, the FLIR Quark is the smallest of its kind. FLIR did not compromise quality for size with the Quark 336, delivering a 336 x 256 resolution it will stand up to any long wave thermal camera.
The FLIR Quark 640 delivers FLIR’s reputable performance in a compact lightweight package. The uncompromising size of the FLIR Quark 640 offers a new variety of uses for R&D applications where size and weight are important factors. Weighing less than 25g and 22 x 22mm in size, the FLIR Quark is the smallest of its kind. FLIR did not compromise quality for size with the Quark 640, delivering a 640 x 512 resolution it will stand up to any long wave thermal camera.).
Lens Options Available:6.3mm, 9mm, 13mm, 14mm, 17mm, 19mm, 25mm, 35mm
This product has been discontinued. Please check out the FLIR Boson as a suitable replacement.
