Teledyne FLIR Neutrino SX8, f/3, with Shutter MWIR Camera Module
- Sensor Size (W x H): 1280 × 1024
- HOT MWIR Sensor Technology
- Pixel Pitch: 8µm
- Size (w/o lens): 7.9 cm × 5.3 cm × 6.1 cm (3.1 × 2.1 × 2.4 in)
- Spectral Band: 3.4µm to ≥ 5.1µm Standard
- Weight: < 420 grams (<15 oz)
- Frame Rate: 60Hz, programmable up to 60Hz
- Aperture: f/3
- Continuous Zoom up to 8X
We usually have a majority of these items in stock.
Please call or contact us for availability.
Neutrino™ SWaP+C Series
Neutrino SX8, f/3, with Shutter
The newly-released SXGA-resolution Neutrino SX8 provides best-in-class MWIR imagery and data in a small, lightweight package. Based on Teledyne FLIR’s High Operating Temperature (HOT) FPA technology and linear micro-cooler, SWaP series OEM camera modules are designed for ruggedized products requiring long life, low-power consumption, and quiet, low-vibration operation. Ideal for small gimbals and airframes, handheld devices, security cameras, targeting devices, and asset monitoring applications.
The Neutrino SWaP Series is simply the best technical solution available. With nearly off-the-shelf delivery (ITAR free), industry-leading two-year warranty, real price competitiveness and well-known product support and product reliability, it also offers the lowest risk solution. The Neutrino SWaP is an OEM camera module that is intended to be integrated into a higher level system.
Superior Performance, Faster Time to Market
MULTIPLE RESOLUTION SWAPOPTIMIZED MWIR CAMERA CORES SXGA/8 µm HOT FPA camera modules in a SWaP-optimized envelope offer low-power consumption, rugged construction, and a wide operating temperature range.
- HOT MWIR Sensor Technology pitch FPA provides superb imagery, 2x faster time to image, and longer cooler lifetime
- Small and light at 7.4 x 4.5 x 6.1 cm and <420 grams
- Low power consumption with <8 W cool down and <4 W steady state @21°C
- Rugged construction and wide operational temperature range of -40°C to +71°C
- Quiet and low vibration operation
DESIGNED FORINTEGRATORS Small, light, and powerful, the Neutrino SWaP Series camera modules come with common interfaces and support documentation/accessories to shorten time-to-market and reduce project risk.
- Built-in support for physical and protocol-level industry standards (e.g. USB2)
- Full suite of hardware accessories
- FLIR XIR™ expandable infrared video processing architecture and robust SDK
- Classified under US Department of Commerce jurisdiction as EAR 6A003.b.4.a
PERFORMANCE, RELIABILITY,AND SUPPORT The Neutrino SWaP Series cameras offer best-in-class image quality, an industry-leading two-year warranty, superior SWaP performance, high reliability, long lifetime, and come with Teledyne FLIR’s well-known product support.
- Industry’s most advanced SWaP+C optimized image processing
- Increased reliability and low-vibration FLIR linear micro-cooler
- Optional integrated shutter provides faster time to image
- Comprehensive product documentation
- Highly-qualified FLIR Technical Services
| Resolution | |
|---|---|
| Pixel Pitch | |
| Spectral Band | |
| Sensitivity/NEdT | |
| FPA & Digital Video Display Formats | |
| Detector Type | |
| f-number | |
| Frame Rate | |
| Image Correction |
DDE, Histogram Equalization, Linear |
| Color and Monochrome Palettes (LUTs) | |
| Continuous Digital Zoom | |
| EFL_Zoom Range [mm] | |
| Operating Temperature Range | |
| Non-Operating Temperature | |
| Operational Altitude | |
| Vibration | |
| Programmable Integration Time | |
| ROIC | |
| ROIC Modes | |
| CMOS (16-bit or 8-bit) |
Yes |
| Weight |
