Teledyne FLIR LWIR CZ 14-75 Lens for Boson+
- 640 x 512 resolution, 12 μm pixel pitch
- LWIR microbolometer
- ≤20 mK thermal sensitivity
- Rugged construction with an operating temperature rating of -40 °C to 80 °C
- Upgraded AGC provides blacker blacks and whiter whites
Interfaces and Accessories sold separately.
We usually have a majority of these items in stock.
Please call or contact us for availability.
Teledyne FLIR CZ 14-75 LWIR Zoom Lens
for Long-Wave Infrared (LWIR) Cameras with 8 – 14 µm
Teledyne FLIR custom and off-the-shelf long-wave infrared (LWIR) continuous zoom (CZ) optical assemblies and lenses are for integrators and operators who do not compromise on quality. All lens assemblies have near diffraction limited performance and include advanced features that ensure continuous focus through the zoom.
Formerly New England Optical Systems (NEOS) and now part of Teledyne FLIR, the world-class technical services team provides product support and can also develop new or customize existing lens assemblies for a camera, application, and mission. Designed to maximize infrared-camera performance, the LWIR CZ lens assemblies provide the competitive advantages required in the field and marketspace for a wide range of defense, security, and commercial applications.
UNCOMPROMISED PERFORMANCE AND RELIABILITY
Designs have near diffraction limited performance through zoom enabling users to Detect, Recognize, and Identify (DRI) threats in real time.
- Optimized for smaller pixel, larger-format focal plane arrays (FPA)
- Elimination of expanders minimizes lens count, maximizes transmission, reduces size & weight, and improves MTF
- Proprietary alignment method improves performance, boresight retention, and reliability through zoom
SMART OPTICS ENSURE CONTINUOUS FOCUS
Control electronics and additional features go beyond simple focus and zoom to provide focus when and where you need it.
- Compensate for range and thermal gradient
- Includes built-in-test (BIT), data logging module, ID module and other features
- High speed communication at 1 kHz
CUSTOM DESIGNS AND SUPPORT FOR THE MISSION
Teledyne FLIR technical services team can develop new or customize existing zoom lens assemblies for a camera, application, and mission.
- Provide the ideal interface to your camera to match cold shield height
- Accommodate operational environment or custom enclosure
- Collaborate and support to make the mission a success
Applications
DEFENSE
- AIRBORNE & GROUND ISR
- REMOTE WEAPON STATION
- TARGETING
- COUNTER-UAS
SECURITY
- BORDER SURVEILLANCE
- PERIMETER SECURITY
- NAVIGATION
- SEARCH & RESCUE
- UAV SYSTEMS
COMMERCIAL
- OEM CAMERA LENSES
- THERMOGRAPHY
| Spectral Band | |
|---|---|
| Focal Length | |
| f-number | |
| Transmission | |
| Distortion | |
| Cold Shield Height |
1.98 mm (camera seats in lens body) |
| Focal Plane Dimension | |
| Minimum Object Distance (meters) |
5 m (WFOV)/50 m (NFOV) |
| Focus/Zoom Mechanism | |
| Focus Change Time | |
| Zoom Time (End to End) | |
| Boresight Drift Through Zoom | |
| Weight | |
| Dimensions (H x W x L) | |
| Control Features |
Built-In Test (BIT), Data Logging Module (optional), Easily Upgradable and Expandable, High Speed Communication – SPI (optional), ID Module, Object Range Compensation, Thermal Gradient Compensation, User Defined Command Aliases |
| Drive Voltage | |
| Current consumption |
Power UP < 0.7 A (20°C), Standby < 0.2 A (20°C), Typical Move < 0.4 A (20°C) |
| Communication Protocol |
RS422, 115200 baud (default), Option: RS232 and programmable baud rate |
| Operating Temperature | |
| Storage Temperature Range | |
| Shock | |
| ESS Vibration | |
| Front Optic Sealing | |
| Back Focal Length | |
| Boson Enclosure Compatible |
