FLIR Duo and Duo R Dual Sensor Drone Cameras

Last Month at the 2017 Consumer Electronics Show (CES) in Las Vegas, Nevada, FLIR announced their latest camera for personal and commercial drone use, the FLIR Duo.

As the most affordable dual thermal and visible sensor drone camera equipped with FLIR’s smallest and lightest Lepton thermal camera core, operators are no longer constrained by daylight. The FLIR Duo provides a sixth sense, the power to see objects over 100 yards away in complete darkness, smoke and light fog. Equipped with a 160×120 thermal camera and High-Definition (HD) 1080 color camera, FLIR Duo allows operators to swap between the two cameras mid-flight or view both in a picture-in-picture mode via the FLIR UAS app, so no flight time is lost swapping out cameras. FLIR’s proprietary MSX image processing algorithm embosses the thermal image with key details from the visible camera, resulting in the sharpest dual-spectrum image in the market.

FLIR also announced a second FLIR Duo camera, the FLIR Duo R priced at $1,299.99. A more professional version of the FLIR Duo, the FLIR Duo R adds accurate temperature measurement capabilities for commercial applications including agricultural, construction, civil engineering, building inspection, and public safety use cases.

Visit www.oemcameras.com to learn how you can take thermal to new heights.

First Responders: FLIR AERIAL Drone Packages available from OEMCameras.com

FLIR AERIAL FIRST RESPONDER KIT

The new FLIR Aerial First Responder Kit will bundle the DJI Inspire 1 drone with the DJI Zenmuse XT stabilized thermal camera powered by FLIR and offered in two configurations, Basic and Advanced.

The Basic bundle includes the 336×256 resolution Zenmuse XT with a 45-degree lens, while the Advanced package sports a higher, 640×480 resolution Zenmuse XT and a 45-degree lens. The Advanced package also includes a second controller so that one controller can be dedicated to aircraft control and the other used for camera control and configuration. All controllers receive live digital video downlink on the Apple iPad Mini included with each controller.

The FLIR-equipped DJI drone packages offer first responders added support with the ability to see through smoke, assess the scene from an aerial perspective, and keep track of their personnel in large fire scenes. For search and rescue operators, they offer valuable observation capabilities in dangerous environments when time is critical.

By combining the flight stability, gimbal technology, mobile app integration, and image transmission of the popular and proven DJI Inspire 1 with the industry-leading thermal imaging technology of FLIR in the Zenmuse XT, these packages are the ultimate solutions for reliable, rapidly-deployable aerial thermal imaging.

The FLIR Aerial First Responder Kits start at $10,450 USD. To learn more about package options, visit www.OEMCameras.com

FLIR VUE PRO R – Radiometric drone camera for accurate airborne temperature measurements

pro_1.fwThe new Vue Pro R from FLIR gives both drone operators and certified thermographers the power to gather accurate, non-contact temperature measurements from an aerial perspective. Every still image the Vue Pro R saves contains accurate, calibrated temperature data embedded in every pixel, adding even more value to your sUAS operations and services than ever.

Keeping the same industry-leading thermal imaging quality, interfaces, and capability as the best-selling Vue Pro, the Vue Pro R adds fully radiometric data-gathering to sUAS applications as diverse as building and roof inspections, power grid inspections, infrastructure analysis, precision agriculture, and public safety.



Radiometryflir_vue_pro_r_tools

The Vue Pro R is more than a thermal imager – it captures accurate, non-contact temperature measurements from an aerial perspective and saves images with calibrated temperature data embedded in every pixel.

Get FLIR Tools

pro_2fw.fw On-Board Recording

Vue Pro R captures regular JPEGs and fully radiometric R-JPEGs that can be fully analyzed in FLIR Tools thermography analysis and reporting software. It also records 8-bit digital video in MJPEG or H.264 formats, and 14-bit TIFFs right on the camera so you won’t lose any of your data to transmission loss. Imagery is saved to the micro-SD card and can be retrieved either directly from the card or by plugging the camera into a USB cable, where your computer will see it as a storage device.

MAVLink Integration & Camera Control

Like Vue Pro, Vue Pro R’s Accessory Port connection gives you access to MAVLink commands camera controls over PWM commands, so you can select color palettes, start and stop recording, or trigger the camera’s e-zoom in-flight from your radio controller. If MAVLink is enabled, two camera controls are available; without MAVLink you can control up to four camera controls.

Easy to Configure

Vue Pro R comes with a built-in, low-power Bluetooth module, so you can easily configure your camera with our custom iOS or Android apps before you take off. Change color palettes, set your image optimization features, configure your PWM inputs, and start recording all without lugging a computer to the field.

With the same powerful thermal imaging core used in the most popular cameras in the world, FLIR Vue Pro R brings affordable, calibrated radiometry to drone operators, making it perfect for myriad applications like:

  • Roof inspections
  • Power line inspections
  • Substation inspections
  • Cell tower inspections
  • Search and rescue
  • Precision agriculture
  • Security
  • Surveying

Introducing the FLIR Boson™

FLIR today announced Boson™, its smallest, lightest, and least power-consuming, high-performance uncooled thermal camera for original equipment manufacturers (OEMs) that make products for firefighting, automotive, maritime, hunting, UAS, and the military. The Boson design allows for expanded computing capability on the camera and a dramatic reduction in price.

Boson

Smaller than the Tau® 2 core, FLIR’s other high-performance uncooled core, and double the size of the low-cost Lepton® core, Boson is the first thermal camera core to incorporate a sophisticated, low-power multi-core vision processor unit that helps make Boson the smartest thermal core on the planet.

Boson uses FLIR’s XIR™ expandable infrared video processing architecture to help OEMs take advantage of advanced image processing and video analytics while keeping power consumption low. Manufacturers of drones, cars, weapons sights and handheld imagers will now have the ability to process video onboard, and allow Boson to do things our previous cores could not::

  • Military: Boson will allow our soldiers on the battlefield to use higher-performance thermal technology that is fit into smaller equipment and distributed more broadly because of the lower prices. It will enable soldiers both on the front lines and command centers to use video analytics to better identify combatant locations or areas for safe deployment.
  • Drones: With a smaller design, the weight difference will help improve battery life and extend flight times. Boson will enable smaller drones with thermal imaging video capabilities that may have been available in only in the highest-end applications like those for military.
  • Automotive: Thermal cameras today provide select luxury automakers a more accurate way to detect people and vehicles on the roadway. By connecting the video analytics built into Boson with a vehicle’s electronics system, cars will require fewer components for integration and more importantly, help improve safety for drivers on the road. With higher-performing capabilities at lower cost, Boson could help make thermal technology more accessible to more vehicles.
  • Firefighting: Firefighters already use thermal imaging cameras, but Boson can enable firefighters to access better, smarter, and smaller thermal devices. The last thing a firefighter wants is another heavy tool. Boson can help control the display, control button functions, improve battery life and lead to a wave of smarter and smaller wearable devices for firefighters. With Boson, more firefighters will have access to higher-performing technology that can improve decision-making when seconds matter.
  • Security:  Boson will enable smaller higher-performing security cameras to be deployed more broadly. When securing high-value areas like airports, stadiums and ports, more security is better. In security, video is data, and it’s impossible for humans to make real-time decisions based on the vast amount of video data. The video intelligence within Boson could help security teams pinpoint if someone is in an area of a stadium where they shouldn’t be, designate the heated object with a box on a video screen and alert security teams.

We’re excited to launch Boson, our first new thermal camera core since Lepton in 2014. We look forward to the range of new products it will enable our OEM partners to develop.

For OEMs who want to consider Boson, it’s available for product development testing now.

To learn more about the technical details for Boson, visit www.oemcameras.com



Source: FLIR

Exclusive: FLIR VUE PRO 35mm Lens



Now available and in stock. FLIR VUE PRO 35mm Lens:
640 Version: 18°(H) x 14°(V) FoV
336 Version: 9.3°(H) x 7.1°(V) FoV

More Info: OEMCameras.com

Designed for professional use the FLIR VUE PRO is more than a thermal camera with Video and Image Capture capabilities adding tremendous value to your sUAS operations and services.
